NEXON

ELECTRICAL

REFITMENT

For refitment follow the procedure in reverse.

1.7.10 FRONT FOG LAMP

The fog lamps are located in the lower part of the

front bumper. The bulb used for the fog lamp

function is a halogen H16 bulb, 12V - 19W.

Fog lamp on/off is done by using master light

switch.

REMOVAL:

1. Disconnect the electrical connection of fog

lamp.

2. Pull out for fitting the lamp housing on the

bumper.
