Diagnostic Trouble Codes List
Sr.
No
DTC
Description as per
ISO/SAE
Fault Cause
Probable Trouble
Area
1
P0914-
02
Gear Position Sensor Circuit–
Fixed Signal High Level
- Short circuit to battery
- Open circuit on Sensor connection Or TCU
- GND loss
- sensor supply loss
- Loose mechanical
fitment of TCU
- Loose mechanical
fitment of Sensor
- TCU internal damage
2
P0914-
01
Gear Position Sensor Circuit–
Fixed Signal Low Level
-Short circuit to ground on sensor
-TCU Connection
- Loose mechanical
fitment of TCU
- Loose mechanical
fitment of sensor
- TCU internal damage
3
P0914-
03
Gear Position Sensor Circuit–
Period Error
-Sensor Problem
- Sensor damage
- TCU internal damage
4
P0914-
05
Gear Position Sensor Circuit–
PWM Duty high
-Sensor Hardware - error
- Sensor damage
- TCU internal damage
5
P0914-
04
Gear Position Sensor Circuit–
PWM Duty low
- Sensor problem (magnet lost)
- Sensor damage
- TCU internal damage
6
P1853-
02
Gear/shift Position Sensor–
Wrong supply voltage Vbatt
Error
-TCU damage
-Short circuit to V supply
on-Sensor supply connection
- Sensor damage
- TCU internal damage
7
P1853-
01
Gear/shift Position Sensor–
Wrong supply voltage GND
Error
-TCU damage
-Short circuit to V supply on-Sensor supply
connection
- Sensor damage
- TCU internal damage
8
P0904-
02
Shift Position Sensor Circuit–
Fixed Signal High Level
-Short to Supply or open circuit on
Sensor(signal)
-Short to Supply or open circuit on TCU
-Sensor GND loss
-Sensor supply loss
- Loose mechanical
fitment of TCU
-Loose mechanical
fitment of Sensor
-Loose or damage or
short circuit internally
-TCU internal damage
9
P0904-
01:
Shift Position Sensor Circuit–
Fixed Signal Low Level
-Short circuit to GND on Sensor
-Short circuit to GND on TCU
- Loose mechanical
fitment of TCU
- Loose mechanical
fitment of Sensor
- Loose or damage or
short circuit internally
-TCU internal damage
10
P0904-
03
Shift Position Sensor Circuit–
Period Error
-Sensor Problem
- Sensor damage
- TCU internal damage
11
P0904-
05
Shift Position Sensor Circuit–
PWM Duty high
-Sensor Hardware error
- Sensor damage
- TCU internal damage
12
P0904-
04
Shift Position Sensor Circuit–
PWM Duty low
-Sensor Algorithm Error (sensor problem,
magnet lost)
- Sensor damage
- TCU internal damage
