TIGOR AMT

546 / 561

TIAGO/TIGOR AMT Gasoline
DTC Troubleshooting Guide
Version: 4.0
Date: 18-04-2017
Author: Sathi/Anupama Page: 412 of 427
Copyright © TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Appendix
Sr.
No.
Display
DTC Code
DTC Description Page
No.
Display
Status
(Mask
Status)
1 P0914-02 Gear Position Sensor Circuit– Fixed Signal High Level 8 N
2 P0914-01 Gear Position Sensor Circuit– Fixed Signal Low Level 11 N
3 P0914-03 Gear Position Sensor Circuit– Period Error 14 N
4 P0914-05 Gear Position Sensor Circuit– PWM Duty high 17 N
5 P0914-04 Gear Position Sensor Circuit– PWM Duty low 20 N
6 P1853-02 Gear/shift Position Sensor– Wrong supply voltage Vbatt Error 23 N
7 P1853-01 Gear/shift Position Sensor– Wrong supply voltage Gnd Error 26 N
8 P0904-02 Shift Position Sensor Circuit– Fixed Signal High Level 29 N
9 P0904-01 Shift Position Sensor Circuit– Fixed Signal Low Level 32 N
10 P0904-03 Shift Position Sensor Circuit– Period Error 35 N
11 P0904-05 Shift Position Sensor Circuit– PWM Duty high 38 N
12 P0904-04 Shift Position Sensor Circuit– PWM Duty low 41 N
13 P0805-02 Clutch Position Sensor Circuit– Fixed Signal High Level 44 N
14 P0805-01 Clutch Position Sensor Circuit– Fixed Signal low Level 47 N
15 P0805-03 Clutch Position Sensor Circuit– Period Error 50 N
16 P0805-05 Clutch Position Sensor Circuit– PWM Duty high 53 N
17 P0805-04 Clutch Position Sensor Circuit– PWM Duty low 56 N
18 P1852-02 Clutch Position/Hyd Press Sensor – Wrong supply voltage Vbatt Error 59 N
19 P1852-01 Clutch Position/Hyd Press Sensor – Wrong supply voltage Gnd Error 62 N
20 P0932-02 Hydraulic Pressure Sensor Circuit– Signal over Max Threshold 65 N
21 P0932-01 Hydraulic Pressure Sensor Circuit– Signal under Min Threshold 69 N
22 P0932-07 Hydraulic Pressure Sensor Circuit– Wrong value sensor 72 N
23 P0932-03 Hydraulic Pressure Sensor Circuit– Wrong signal spikes 75 N
24
P0820/P0
821/P082
2/P0823-
02
Gear Lever Sensor Circuit– Over Max Threshold 78 N
25
P0820/P0
821/P082
2/P0823-
01
Gear Lever Sensor Circuit– Under min. Threshold 82 N
26 P0825 -02 Gear Lever Sensor Circuit– Signal Not valid 86 N
27 P0825 -01 Gear Lever Sensor Circuit– Misuse 90 N
28 P0715 -03 Clutch Speed Sensor Circuit– Signal absent 95 N
29 P0715 -01 Clutch Speed Sensor Circuit– Signal Wrong 98 N
30 P0715 -02 Clutch Speed Sensor Circuit– Signal Wrong Spikes 101 N
31 P2900 -01 Sport Switch input circuit – Switch Stuck 104 N
32 P0725 -02 Engine Speed Input Circuit– Signal not valid 107 N
33 P0725-03 Engine Speed Input Circuit– Signal Absent 110 N
