ECM ECU Pin assignment:-
Connector
No.
Pin No.
Pin Name
Description
Vehicle Connector-1
C1,32 CAN_H
CAN High
C1,44 CAN_L
CAN Low
C1,16 Ign
Ignition
C1,55;
C1,56
Vbat
Supply Voltage Battery
C1,53;
C1,54
GND
Battery GND
