ECM ECU Pin assignment:-
Pin no
Pin Name
Description
19
CAN_H
CAN High
18
CAN_L
CAN Low
49
Ign
Ignition
12,31
Vbat
Supply Voltage/ Battery
9,28
GND
Battery GND
