P0880- 06: SMP 5V power Supply – under medium threshold
Overview:
ISO Code
P0880- 06
Customer Symptom
Transmission Fault Lamp ON,
Vehicle shifting to neutral when idling
Fault Effects (On Vehicle)
Vehicle shifting to neutral when idling
Lamp Status (If Any)
Transmission Fault Lamp ON
Fault Detection Condition
This fault gets detected after Ignition On if the TCU detects
that the 5 V safety processor supply is below a medium
threshold.
Normal Operating Condition
5 V safety processor supply is within limits
Probable Trouble Area
TCU damage
Healing Condition
50ms after detection of valid heal condition
Component Details:
The Problem may occur due to an internal damage to TCU.
Preliminary Checks:
1) Battery voltage
2) Check for damage or back out of pins at TCU connectors.
3) Check correct fitment of ground cable connections on vehicle chassis (tightness, corrosion of mounting bolts etc.)
.
Trouble Shooting:-
Step Checks
IF YES
IF NO
1
At the first instance of the fault, clear the
DTC and run the vehicle in all gears for
about 10 kms, does the fault recur?
Go to Step 2
Release the vehicle
to the customer
after final drive test
2
Check Battery and Ignition supplies at pins
1,3and 5 respectively. Both are correct?
Go to Step 3
rectify harness
connections as per
the circuit
schematic
3
Is there any pin back
out/damage/rust/oxidation observed on
TCU Connector?
Clean or repair or replace connector Go to Step4
4
Fault Still Persists?
Replace TCU
Follow the steps
again for
reconfirmation
DTC’s confirmation:-
After rectification, clear all DTC’s and ensure the following points by referring TCU parameters using TML diagnostic tool
before handing over to customer.
Drive the vehicle through all gears in both Automatic and Manual modes
Ensure no DTC is active and Transmission Fault Lamp is OFF.
Circuit Schematic Diagram:
Component Location & Image:-
Connector Location: -
Connector View & Information: -
