110.
P184D- 02: Electro valves Driver 2– SPI Device fault
Overview:
ISO Code
P184D- 02
Customer Symptom
Transmission Fault Lamp ON, No gearshifts,Vehicle not
picking up, engine stopping, gear shift request by lever
disabled
Fault Effects (On Vehicle)
No gearshifts , Vehicle not picking up, engine stopping, gear
shift request by lever disabled
Lamp Status (If Any)
Transmission Fault Lamp ON
Fault Detection Condition
This fault gets detected after Ignition On if the TCU detects a
parity bit failure on the Electro valve driver data.
Normal Operating Condition
The electro valves data integrity is validated to be correct.
Probable Trouble Area
TCU damage
Healing Condition
50 milliseconds after valid signal
Component Details:
The Problem may occur due to an internal damage to TCU.
Preliminary Checks:
4) Battery voltage
5) Check for damage or back out of pins at TCU connectors.
6) Check correct fitment of ground cable connections on vehicle chassis (tightness, corrosion of mounting bolts etc.)
.
Trouble Shooting:-
Step Checks
IF YES
IF NO
1
At the first instance of the fault, clear the
DTC and run the vehicle in all gears for
about 10 kms, does the fault recur?
Go to Step 2
Release the vehicle to the
customer after final drive
test
2
Check Battery and Ignition supplies at pins
1,3and 5 respectively. Both are correct?
Go to Step 3
rectify harness
connections as per the
circuit schematic
3
Is there any pin back
out/damage/rust/oxidation observed on
TCU Connector?
Clean or repair or replace
connector
Go to Step4
4
Fault Still Persists?
Replace TCU
Follow the steps again for
reconfirmation
DTC’s confirmation:-
After rectification, clear all DTC’s and ensure the following points by referring TCU parameters using TML diagnostic tool
before handing over to customer.
Drive the vehicle through all gears in both Automatic and Manual modes
Ensure no DTC is active and Transmission Fault Lamp is OFF.
Circuit Schematic Diagram:
Component Location & Image:-
Connector Location: -
