DTC P0710-02), are sensor connections
OK?
operation (refer DTC
P0710-04).
6
Clear the DTC and drive the vehicle through
all gears for 10 kms. Key OFF, repeat this
cycle 5 times. Is the fault recurring?
Replace clutch
Release vehicle to the
customer after final drive
test
DTC’s confirmation:-
After rectification, clear all DTC’s and ensure the following points by referring TCU parameters using TML diagnostic tool
before handing over to customer.
Pickup the vehicle to 20 Kmph under heavy throttle (>50%), and decelerate to standstill, do this for 10 cycles and
monitor the clutch temperature and ensure it is less than xyz.
Drive the vehicle through all gears in both Automatic and Manual modes
Ensure no DTC is active and Transmission Fault Lamp is OFF.
Circuit Schematic Diagram:
