994 / 1131
ELECTRICAL
224
WARNINGS
1. The camera uses fish eye lens. So the size of
the objects or distance from the objects that
appear in the display may differ from the actual
distances and size.
2. In low light conditions, the screen may darken
or image may become faint.
3. If the tire sizes are changed, the position of the
fixed guidelines displayed on the screen may
change.
4. Do not apply any kind of force on the camera.
5. During rainy or snowy conditions, image may
get obscured. So in this condition, do not
depend on park aid system.
6. The camera used in the vehicle, may not
reproduce the same color of the real object.
7. The rear view camera does not display objects
that are close to or below the bumper,
underneath the vehicle, or objects out of the
camera’s field of view. The area displayed on
the screen may vary according to vehicle
orientation or road conditions.
8. In case of damage of the rear portion of the
vehicle, camera position may change. Which
causes wrong visual information on display. In
case of damage, make sure that, camera fitted
properly at the intended location.
9. In case of uneven road conditions or up –hill or
downhill conditions, do not depend on rear
view camera park aid.
10.High humidity and variation in ambient
temperature may result into condensation
inside the camera lens, which may further
result into degradation of camera video feed
on the screen. It is recommended that not to
rely on camera video feed for parking
assistance in such scenario. This phenomena
is temporary and will be automatically
recovered with reduction in humidity and less
variation in ambient temperature.
USING CAMERA
1. As the camera is waterproof construction, do
not detach, disassemble or modify in any
manner from the actual position. This will show
in correct visual information in display.
2. Do not use camera when back door is open. If
back door is open, visual information may not
be the actual rear view of the vehicle.
3. When the camera is operated under
fluorescent lights, sodium light or mercury light
etc., illuminated areas on the lens may appear
to flicker in the display.
4. Do not attach any advertisement or styling or
any kind of stickers on top of camera. If this
happens, camera cannot provide you the
visual image.
