NEXON

ELECTRICAL

126

TELL TALES

COLOR

INDICATOR

REMARKS

Seat belt

warning

Red

Seat belt warning indicator comes ‘ON’ for 4 seconds, when

ignition is turned ‘ON’.

If seat belt is not fastened and lamp shall be made ON

continuously for 30 sec.

If seat belt is not buckled and vehicle speed goes above 4

kmph, Telltale shall be ON as initial warning with No audio

chime. Telltale shall turn OFF when vehicle speed goes

below 2 kmph.

If seat belt remains unbuckled and vehicle speed goes

above 15 kmph, Final Waring shall start. Audio Chime shall

continue for 30 seconds. Seat belt telltale shall remain

continuously ON when audio alarm is active.

Seat belt audio alarm shall not turn ON if reverse gear is

engaged.

Airbag status

Red

Illuminates momentarily when ignition is switched ‘ON’ once

engine is cranked, it goes OFF.

It will continuously illuminate when there is malfunction of

airbag (SRS) system. Contact TATA MOTORS Authorized

Service Centre urgently.

EPAS

Amber

Illuminates momentarily when ignition is switched ‘ON’ once

engine is cranked, it goes OFF.

Illuminates when there is a fault in the EPAS. Contact

TATAMOTORS Authorized Service Centre urgently.

Low Coolant

Temperature

Blue

Indicates that engine coolant temperature is very low.

Illuminates

when engine coolant temperature is very low

and continuously

flashes along with buzzer if engine coolant

temperature is extremely low. Contact TATA MOTORS

Authorized Service Centre urgently.

High Coolant

Temperature

Red

Indicates that engine coolant temperature is very high.

Illuminates when engine coolant temperature is very high

and continuously flashes along with buzzer if engine coolant

temp. is extremely high. Switch off the engine and allow

cooling. Top-up coolant if coolant level is low. Contact TATA

MOTORS Authorized Service Centre urgently.

Low Fuel

Amber

Illuminates momentarily when ignition is switched ‘ON’ once

engine is cranked, it goes OFF. Illuminates continuously if

fuel level is less than a pre-defined minimum level. Refill the

fuel tank as soon as possible. IMPORTANT: The warning

light flashes to indicate a fault in fuel system. Contact TATA

MOTORS Authorized Service Centre urgently.

NOTE: Driving with low fuel level condition can cause the

engine to misfire and damage the catalytic converter (if

equipped).
