902 / 1131
ELECTRICAL
132
7
Outside
Ambient
Temperature
Displays outside ambient temperature in units
°C or °F.
Resolution: 1 °C or °F
Note:
User can change the Temperature unit using
SET and MODE buttons and °F is applicable
for Export variant only.
The temperature sensor is in the front
bumper of the vehicle, therefore the
temperature reading can be affected by heat
reflection from the road surface, engine heat
and the exhaust from surrounding traffic. This
can cause an incorrect temperature reading
when speed is under low speeds or when
stopped.
If display shows ‘- - ‘, take your car to TATA
authorized service Centre.
8
Service reminder
Indicates the number of days or kilometers
remaining for next service at every ignition
ON for few seconds if service is due.
If service is overdue, DIS shall display 0 km
or 0 days and spanner symbol shall blink at
every ignition ON for few seconds.
DIS shall indicate Spanner symbol as
continuously ON when service is overdue.
When Service reminder warning appears,
take your vehicle to Authorized TATA
MOTORS service station.
Note1:
Take vehicle to Authorized service station
only for servicing.
Note2:
The service reminder through instrument
cluster is just for an indicative purpose.
Please refer the Maintenance and Service
section in owner’s manual for extensive
information on service schedules.
9
Door Ajar
Indicates the door ajar warning.
Applicable to XT, XZ, XZA, XZO variant.
All four doors and tail gate shall be
indicated independently when respective
door open.
