BODY
52
10. Remove Spring Band Clamp from Fuel Filler
Pipe and separate it from Fuel Filler Hose.
11. Remove Spring Band Clamp from Breather
Pipe and separate it from Breather Hose.
12.Pull out the fuel filler pipe assembly behind the
fuel filler housing and take it out.
FITMENT
For fitment follow reverse procedure of removal.
1.4.39. FRONT WHEEL ARCH LINER
REMOVAL
1. Remove three mounting screw holding front
bumper from bottom.
2. Remove two mounting screw located inside
the arch liner.
3. Pull out tree clips.
