NEXON

BODY

1.4.24. REAR ROW SEAT

REMOVAL

1. Lift Rear Seat back lock.

2. Fold the seat backrest.

3. Remove rear seat backrest side bracket

mounting fasteners from both side and remove

rear seat backrest assembly.

4. Pull out C Pillar lower. (For procedure refer C

pillar removal process.)

5. Remove mounting bolt of seat belt striker from

both side and take it out.

6. Remove four Rear Seat mounting screw as

shown in figure.

7. Remove Rear Seat.

FITMENT

1. Fit rear seat backrest side bracket mounting

fasteners from both side.
