TRANSAXLE TA6300
28
15. Unscrew hex Flange screw M8x22 & take out
reverse Lever bracket Assy.
16. Take out input shaft assembly, Lay shaft
assembly, reverse shaft assembly & all shifter
shaft assembly as shown
17. Remove wiring harness Bracket.
18. Remove cable-anchoring Bracket.
19. Remove the differential assembly along with
taper roller bearing from the housing front.
20. Remove oil seals of drive shaft from housings.
Replace it with a new one while
assembling.
21. Remove Outer race taper bearing of
differential from front housing with the help of
puller 5438 5980 2603.
22. Remove Outer race cylindrical roller bearing
of lay shaft from front housing with the help of
puller 5438 5980 2603.
