1.5L REVOTORQ ENGINE
54
8. Drain the coolant reservoir and rinse out any
sediment.
9. Use fresh water to reverse flush the radiator
from the drain to the coolant reservoir bottle.
10. Secure the coolant reservoir bottle in the
engine compartment using the fasteners
removed previously.
11. Close the coolant drain plug on the radiator.
12. Add the recommended brand of pre-mixed
40:60 ratio coolant to the reservoir until the
coolant level is
at the 'MAX' mark on the
bottle.
13. Start the engine and gradually increase
engine speed to allow the engine to reach 85-
90
o
C, which allows the thermostat to open.
14. Allow the engine to return to idle speed.
15. Stop the engine and allow to cool sufficiently.
16. Add pre-mixed 40:60 ratio coolant to the
reservoir until the coolant level is at the 'MAX'
mark on the bottle.
iii. AIR FILTER ELEMENT REPLACEMENT
DESCRIPTION
Proper maintenance of the air filter is essential
for vehicle performance and fuel economy. The
air filter element removes foreign material such
as dust, dirt, and other material from the
intake air, thereby preventing the engine from
damage due to contaminated air.
Inspect and clean the air filter element at every
routine service. Replace the air filter element as
per service schedule.
REMOVAL
1. Park the vehicle on a level surface, engage
the parking brake, and raise the hood.
2. Unscrew the top three mounting bolts of air
filter assembly & one locator point at back
side.
3. Detach the cover through hinge action, with
clamp and snorkel intact with cover.
4. Remove the air filter element.
5. Gently tap loose any dirt or debris from the
filter. Clean the housing and air ducts as
well. Take care not to allow dirt and debris to
enter the air inlet to the engine.
