1.5L REVOTORQ ENGINE
46
Crankcase and Components
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Cylinder Crankcase (Non Linered)
02
Stiffening Bracket Assy., Front
03
Hex. Flange Screw M10x18 (Qty. 2)
4.0
04
Hex. Bolt (M. B. Cap) (Qty. 10)
5.0 +
90
ᵒ
turn
05
Main Bearing Cap (Qty. 5)
06
Dipstick Tube Assy.
07
Dipstick Assy.
08
Gasket, Cylinder Head
09
Hex. Flange Screw M10x22 (Qty. 2)
4.0
10
Stiffening Bracket Assy.
11
Hex. Flange Screw M10x30 (Qty. 2)
4.0
12
Stiffener Bracket, Powertrain,
13
Cover, Crankcase, Rear
14
Screw M6x20 (Qty. 6)
1.0+0.2
15
Crankshaft Oil Seal (Rear)
16
Rubber Asbestos Gasket 0.5 Thk
