1.5L REVOTORQ ENGINE
42
EGR Valve, Thermostat and Components
ITEM
NO.
DESCRIPTION
NO REUSESEALANT
LUBRICATIONTIGHTENING
TORQUE
(kg-m)
01 Assy., EGR Valve
02 Stud C M6x20 (Qty. 2)
03 Hex. Flange Nut Am6 (Qty. 2) 1.0 + 0.2
04 Stud C M6x45 (Qty. 4)
05 Paper Gasket 0.5 Thk
06 EVRV Hose, EVRV To EGR Valve
07 Hex. Flange Screw M6x12
08 Hex. Flange Screw M8x14 (Qty. 2)
09 Bracket Vacuum Reservoir Mtg.
10 Bracket, Vacuum Reservoir
11 Gasket (IC Pipe To Intake Manifold)
12 Hex. Flange Screw M8x14
13 Pan Head Tap Screw
14 Vacuum Reservoir
15 Hose (T-Connector To Reservoir )
16 Hose Brake Line To NRV
17 One Way Check Valve
18 Hose NRV To T Connector
19 T-Connector
20 Hose EVRV To VGT
21 Hose T-Connector To EVRV End
22 Hose EVRV To T-Connector
23 T-Connector
24 Hose EVRV To T-Connector
25 Bracket Assy., EVRV Mounting
