281 / 1131
1.5L REVOTORQ ENGINE
26
Starter Motor, Compressor and Alternator
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Starter Motor
02
Bracket Assy., Solenoid Mounting
03
Hex. Flange Bolt M8x65
2.4
04
Hex. Flange Screw M6x12
05
Heat Shield, Starter Motor
06
Bracket Compressor Mounting -
07
Hex. Flange Bolt M8x22 (Qty. 4)
2.5
08
Compressor Assy. 1.5L
09
Hollow Dowel (Qty. 2)
10
Hex. Flange Bolt M8x75 (Qty. 3)
2.5
11
Poly V-Belt, AC Compressor (5PK, 727L)
12
Vibration Damper Assy. (5-Grooves)
13
Screw M8x20 (Qty. 4)
2.5
14
Washer (Crankshaft Gear)
15
Hex. Bolt (Crankshaft Gear) (M16x61)
4.0 + 60°
16
Hex. Flange Screw M8x14
17
Hex. Flange Bolt M8x135
2.0
18
Bracket Alternator, Bottom Support
19
Alternator Belt
20
Alternator
21
Hex. Flange Screw M8x22 (Qty. 4)
2.0
22
Bracket Alternator, Top Support
23
Hex. Flange Screw M8x16
24
Hex. Flange Bolt M8x55
2.0
25
Bracket Alternator (For Alternator Mtg.)
