NEXON

287 / 1131

1.5L REVOTORQ ENGINE
32
Exhaust manifold, Catcon, Turbocharger
ITEM
NO.
DESCRIPTION
NO REUSESEALANT
LUBRICATIONTIGHTENING
TORQUE
(kg-m)
01 Turbocharger Assy.
02 Heat Shield Assy.,Turbocharger -
03 Hex. Flange Screw M8x25 (Qty. 2) 1.5
04 Gasket (TC Outlet To Cat. Con.)
05 Close Coupled Catcon Assy.
06 Hex. Flange Bolt M8x22 3.0
07 Hex. Flange Screw M8x18 (Qty. 2) 3.0
08 Bracket Assy. (CCC Support)
09 Flanged Clinch Nut (Qty. 10) 2.0 + 0.3
10 Stud C M8x32 (Qty. 10) 2.0 + 0.3
11 Exhaust Manifold
12 Gasket, Exhaust Manifold
13 Hex. Flange Screw M8x18 (Qty. 2) 1.5
14 Heat Shield Assy., Exhaust Manifold, Top
15 Gasket, TC Intake To Exhaust Manifold
16 Stud C M8x32 (Qty. 2) 2.0 + 0.3
17 Flanged Clinch Nut (Qty. 3) 3.0
18 Bracket, Turbocharger (Turbo Support)
19 Hex. Flange Nut Am8 2.0
20 Bracket (Turbo Support)
21 Hex. Flange Bolt M8x38 2.0
22 Flanged Clinch Nut (Qty. 3) 3.0
