TIAGOR

698 / 1034

ELECTRICAL
77
PIN DESCRIPTION
1 -ve
2 +ve
A PILLER TWEETER REMOVAL:
1. Remove the A-pillar trim. (Refer Body section)
2. Disconnect the electrical connection of
tweeter.
3. Loosen and remove the two mounting screws
of tweeter.
REFITMENT
For refitment follow the procedure in reverse.
REAR DOOR TWEETER REMOVAL:
1. Remove the rear door trim (Refer the body
section).
2. Disconnect the electrical connection of
tweeter.
3. Loosen and remove the two mounting screws
of tweeter & Take out the tweeter.
REFITMENT
For refitment follow the procedure in reverse.
