ENGINE
42
Fitment :
For fitment follow the reverse order of removal.
Using hand priming pump refill the fuel lines.
DRAINING WATER FROM FUEL FILTER :
The procedure to drain water from fuel filter is
same as that of sedimentor. Instead of sensor
(as
in sedimentor)
the drain plug has to be loosened
by 2 turns and approximately 120cc of diesel has
to be drained.
v.
Draining Water From Pre-Filter Cum
Sedimentor :
1. Stop the engine allow the pressure to
stabilize.
2. Disconnect the sensor pigtail and also
disconnect one of the fuel lines either inlet or
outlet.
3. Keep a suitable container to collect the
drained water.
4. Rotate the sedimentor sensor in an anti-
clockwise direction for about 2 turns and allow
approximately 120cc of diesel to drain and
then tighten the sensor.
5. Connect the fuel line and pigtail that was
disconnected in step 2.
6. Using hand priming pump refill the fuel line.
NOTE
For priming procedure refer fuel system in
this group.
