ENGINE
34
Engine Timing :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Timing Belt
02
Timing Gear (Camshaft) (Front)
03
Washer (Camshaft Gear)
04
Hex Bolt (Camshaft Gear)
11
±0.5
05
Auto Tensioner Assembly
06
Hex FL Nut AM8 (Qty – 1)
3
07
Hex FL Bolt M8X35 (Qty – 1)
2.5
+0.3
08
Assembly Touch Idler
09
Hex FL Bolt M10X75 (Qty – 1)
8
+0.5
10
Idler Pulley
11
Hex FL Screw M6X20 (Qty – 6)
1
±0.15
12
Assembly Water Pump
13
Gasket (Water Pump)
14
Nut (FIP Gear)
6.6
±0.5
15
Timing Gear (FIP)
