464 / 1906
ENGINE
32
Moving Parts :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Top Ring
02
Second Ring
03
Gudgeon Pin
04
Internal Round Wire Circlip
05
Bolt (Connecting Rod) (Qty – 8)
Step 1-
2.9±0.3
torque
Step 2-
110
0
±10
0
torque
06
Connecting Rod Bearing (Upper)
07
Crankshaft
08
Friction Plate (On Crankshaft)
09
Crankshaft Gear
10
Washer (Crankshaft Gear)
11
Hex Bolt (On Crankshaft)
Step 1-
9±1 torque
Step 2-
110
0
±10
0
torque
12
Assembly Vibration Damper
13
Connecting Rod Bearing (Lower)
14
Connecting Rod Bearing Cap
15
Flange Nut (Qty – 8)
16
Thrust Washer Lower Half
17
Main Bearing Lower Shell
18
Main Bearing Upper Shell
19
Thrust Washer Upper Half
20
Flexplate Assembly
21
Hex Bolt (Flexplate Mounting) (Qty – 8)
22
Connecting Rod
23
Piston Assembly
24
Oil Control Ring
