ENGINE
36
Fuel Injection Equipment :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
FIP Mounting Bracket
02
Hex FL Screw M8X30 (Qty – 3)
2.2
+0.3
03
Hex FL Screw M8X30 (Qty – 2)
2.2
+0.3
04
Hex FL Screw M8X22 (Qty – 1)
2.2
+0.3
05
High Pressure Pump Assembly
06
HP Pipe (Pump to Rail)
07
Hex FL Bolt M8X40 (Qty – 3)
2.2
+0.3
08
Assembly Fuel Rail
09
Cap Nuts (HP Line)
3
± 0.2
10
HP Pipe (Rail to Injector)
