STEERING
42
ii. SUCTION PORT CONNETOR :
Dismantling:
1. Loosen and remove two Allen screws of the
suction connector.
2. Remove the suction connector, spring washer
and “O” ring.
INSPECTION:
Check for any external damage and scoring
marks and sealing areas.
ASSEMBLY:
1. Assemble the “O” ring on the suction port.
2. Assemble suction port connector with the
pump assembly and tighten the allen head
screws along with the spring washers to the
specified torque.
