113.

P0881- 03: TCU 12V Internal Supply Device closed*

*This particular fault may not be detectable with the diagnostic tool as TCU will fail to run.

Overview:

ISO Code

P0881- 03

Customer Symptom

No gearshifts ,

Vehicle not cranking,

Vehicle not picking up,

vehicle stuck in gear while driving ,

gear shift request by lever disabled

Fault Effects (On Vehicle)

No gearshifts ,

Vehicle not cranking,

Vehicle not picking up,

vehicle stuck in gear while driving ,

gear shift request by lever disabled

Lamp Status (If Any)

Transmission Fault Lamp OFF

Fault Detection Condition

This fault gets detected after Ignition On if the TCU detects

that the +12V internal supply of the TCU is above a threshold.

Normal Operating Condition

+12V supply of the TCU is in a proper range

Probable Trouble Area

TCU damage

Healing Condition

50 milliseconds after valid signal

Component Details:

The Problem may occur due to an internal damage to TCU.

Preliminary Checks:

1) Battery voltage

2) Check for damage or back out of pins at TCU connectors.

3) Check correct fitment of ground cable connections on vehicle chassis (tightness, corrosion of mounting bolts etc.)

Trouble Shooting:-

Step Checks

IF YES

IF NO

At the first instance of the fault, clear the

DTC and run the vehicle in all gears for

about 10 kms, does the fault recur?

Go to Step 2

Release the vehicle

to the customer after

final drive test

Check Battery and Ignition supplies at pins

1,3and 5 respectively. Both are correct?

Go to Step 3

rectify harness

connections as per

the circuit schematic

Is there any pin back

out/damage/rust/oxidation observed on

TCU Connector?

Clean or repair or replace

connector

Go to Step4

Fault Still Persists?

Replace TCU

Follow the steps

again for

reconfirmation

the following points by referring TCU parameters using TML diagnostic tool

before handing over to customer.

Drive the vehicle through all gears in both Automatic and Manual modes

Ensure no DTC is active and Transmission Fault Lamp is OFF.
