Using TCU diagnostic tool, initiate a grid

learning procedure

Are gears engaging and disengaging freely

and grid learning is successfully executed?

Recheck the above steps

Replace parts in following

order and re-verify:

1>Valve body (MGA)

2>Gearbox

3>Entire Transmission

the following points by referring TCU parameters using TML diagnostic tool

before handing over to customer.

Drive the vehicle through all gears in both Automatic and Manual modes

Ensure no DTC is active and Transmission Fault Lamp is OFF.

Circuit Schematic Diagram:
