Tiago AMT Routine Procedure for Component replacement
Version: 1.0
Date: 04-Jan-17
Author:
Suraj Anupama Gore
Page: 13 of 18
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
10.
After the above routine, ensure power latch of 30 sec (Ignition should be OFF for 30 sec).
11.
Now turn ON Ignition only and keep engine OFF.
12.
The precondition for “Grid Self Tuning” routine as are as below:
a. Ignition ON
b. Gear box in Neutral
c. Engine is OFF
13.
Perform “Grid self-tuning” through service Tool.
14.
After the above routine, ensure power latch of 30 sec (Ignition should be OFF for 30 sec)
15.
Now turn on Ignition and crank the engine and ensure that engine is running.
16.
Ensure that following precondition “Clutch kiss point self-tuning“ routine as are as below:
a. Ignition ON
b. Gear box in Neutral
c. Engine is running in idle.
17.
Perform “Clutch kiss point self-tuning“ routine through service Tool
18.
After the above routine, ensure power latch of 30 sec (Ignition should be OFF for 30 sec).
19.
Switch on Ignition, Clear DTC and Check DTC if any.
6.9
Routine Procedure for Primary shaft speed sensor replacement
1.
The precondition for “Hydraulic Circuit Depressurization” routine as are as below:
a. Ignition ON
b. Gear box in Neutral
c. Engine is OFF
d. Press brake during routine
2.
Perform “Hydraulic Circuit Depressurization” routine in service Tool.
3.
After the above routine, ensure power latch of 30 sec.(Ignition should be OFF for 30 sec)
4.
Refer guidelines by Transmission to replace and fitment New Sensor on the vehicle.
5.
Switch on Ignition, Clear DTC and Check DTC if any.
