INSTRUEMENT CLUSTER
1
1. GENERAL INFORMATION
FEATURES
Dynamic and monitoring information (e.g. fuel level) to which the driver should respond, is indicated in the
instrument cluster.
The Instrument Cluster has following features:
Analogue Gauge : Speedometer, Tachometer and Fuel gauge
Bar graph: Engine coolant Temperature (as a part of LCD display), Fuel gauge
LCD Display : Clock, Odometer & Trip meter (A & B)
Tell tales
Mode & Set switches
High End Instrument Cluster
Low End Instrument Cluster
