TA65 Star AMT
23
17. Remove Housing mounting bolts on Engine
from top side.
18. Uplift the car on post & give support to Engine
using lifting Device.
19. Remove Housing mounting bolts on Engine
from Bottom side.
20. Remove Electrical connection of Speed
Sensor & to AMT Kit.
21. Disconnect C mountings as shown
22. Lastly Remove Gear Box Rounding Bolt
23. Lower Gear Box with AMT KIT.
24. Remove Nyloc nut on AMT & take out AMT
Kit from Gear Box.
25. Remove the cooling module of the vehicle
(Refer Remove and Re-fitment of cooling
module in engine).
26. Remove fuel line supporting bracket from
clutch housing.
INSTALLATION OF TRANSAXLE
Follow the Reverse Procedure as given above
