TIAGO AMT Gasoline
DTC Troubleshooting Guide
Version: 2.0
Date: 06-06-2016
Author: Sathi/Anupama
Page: 5 of 424
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
68.
P081A-03: Cranking Enable Short to ground/open circuit
........................................................................... 216
69.
P081A-02: Cranking Enable Short to supply
................................................................................................. 218
70.
P1884-04: Reverse Lamp relay open circuit
.................................................................................................. 221
71.
P1884-02: Reverse Lamp relay short to supply
............................................................................................ 224
72.
P1884-01: Reverse Lamp relay short to ground
........................................................................................... 227
73.
P2904-01: Clutch System Not opening before shift
..................................................................................... 230
74.
P2904-02: Clutch System Closing during Engage
....................................................................................... 233
75.
P2904-03: Clutch System Overheat
............................................................................................................... 236
76.
P2908-01: Clutch System Control error
......................................................................................................... 240
77.
P1905-02: Clutch System Clutch locked
....................................................................................................... 242
78.
P2905-01: Gearbox System Disengage failed
............................................................................................. 245
79.
P2909-01: Gearbox System Shift failed
........................................................................................................ 249
80.
P2905-02: Gearbox System engage failed
.................................................................................................... 253
81.
P2905-03: Gearbox System unintended disengage
..................................................................................... 257
82.
P2909-02: Gearbox System Shift Locked
...................................................................................................... 261
83.
P190B-01: Gearbox System unintended engage
......................................................................................... 265
84.
P190C-07: Gearbox System Control Error
..................................................................................................... 268
85.
P190D-01: Gearbox System Clutch over speed
........................................................................................... 271
86.
P0942- 01: Hydraulic Circuit Pressure Low
.................................................................................................. 274
87.
P0942- 07: Hydraulic Circuit Pump Overheating
......................................................................................... 278
88.
P2712- 07: Hydraulic Circuit Leakage too high
............................................................................................ 282
89.
P2901- 01: Hydraulic Circuit Accumulator discharged
................................................................................ 285
90.
P0780- 07: Hydraulic Circuit System Misuse
............................................................................................... 288
91.
P184A- 01: Hydraulic Circuit Pump Timeout
................................................................................................ 291
92.
P0562-04: Battery Supply 1 Open circuit
....................................................................................................... 294
93.
P0560-01: Battery Supply 1 Wrong Value
..................................................................................................... 297
94.
P0560-02: Ignition Key voltage Wrong Value
................................................................................................ 300
95.
P0945-04: Battery Supply 2 Open circuit
...................................................................................................... 303
96.
P1711-01: Battery Supply under shift threshold
........................................................................................... 306
97.
P1711-02: Battery Supply over threshold
.................................................................................................... 308
98.
P1711-07: Battery Supply under low threshold
............................................................................................ 310
99.
P0604- 08: TCU ROM Checksum Error *
....................................................................................................... 312
100.
P0604- 07: TCU RAM Integrity Error *
............................................................................................................ 314
101.
P062F- 07: TCU EEPROM Tuning Data Alteration Error
............................................................................ 316
