TIAGO AMT Gasoline
DTC Troubleshooting Guide
Version: 2.0
Date: 06-06-2016
Author: Sathi/Anupama
Page: 3 of 424
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Table of Contents
1.
P0914-02: Gear Position Sensor Circuit Fixed Signal High Level
...................................................................... 8
2.
P0914-01: Gear Position Sensor Circuit Fixed Signal Low Level
.................................................................... 11
3.
P0914-03: Gear Position Sensor Circuit Period Error
........................................................................................ 14
4.
P0914-05: Gear Position Sensor Circuit PWM Duty high
.................................................................................. 17
5.
P0914-04: Gear Position Sensor Circuit PWM Duty low
................................................................................... 20
6.
P1853-02: Gear/shift Position Sensor Wrong supply voltage Vbatt Error
....................................................... 23
7.
P1853-01: Gear/shift Position Sensor Wrong supply voltage Gnd Error
........................................................ 26
8.
P0904-02: Shift Position Sensor Circuit Fixed Signal High Level
.................................................................... 29
9.
P0904-01: Shift Position Sensor Circuit Fixed Signal Low Level
..................................................................... 32
10.
P0904-03: Shift Position Sensor Circuit Period Error
..................................................................................... 35
11.
P0904-05: Shift Position Sensor Circuit PWM Duty high
............................................................................... 38
12.
P0904-04: Shift Position Sensor Circuit PWM Duty low
................................................................................ 41
13.
P0805-02: Clutch Position Sensor Circuit Fixed Signal High Level
............................................................. 44
14.
P0805-01: Clutch Position Sensor Circuit Fixed Signal low Level
............................................................... 47
15.
P0805-03: Clutch Position Sensor Circuit Period Error
................................................................................. 50
16.
P0805-05: Clutch Position Sensor Circuit PWM Duty high
........................................................................... 53
17.
P0805-04: Clutch Position Sensor Circuit PWM Duty low
............................................................................. 56
18.
P1852-02: Clutch Position/Hyd Press Sensor Wrong supply voltage Vbatt Error
.................................... 59
19.
P1852-01: Clutch Position/Hyd Press Sensor Wrong supply voltage Gnd Error
...................................... 62
20.
P0932-02: Hydraulic Pressure Sensor Circuit Signal over Max Threshold
................................................ 65
21.
P0932-01: Hydraulic Pressure Sensor Circuit Signal under Min Threshold
............................................... 69
22.
P0932-07: Hydraulic Pressure Sensor Circuit Wrong value sensor
............................................................ 72
23.
P0932-03: Hydraulic Pressure Sensor Circuit Wrong signal spikes
............................................................ 75
24.
P0820/P0821/P0822/P0823-02: Gear Lever Sensor Circuit Over Max Threshold
.................................... 78
25.
P0820/P0821/P0822/P0823-01: Gear Lever Sensor Circuit Under min. Threshold
................................. 82
26.
P0825 -02: Gear Lever Sensor Circuit Signal Not valid
................................................................................. 86
27.
P0825 -01: Gear Lever Sensor Circuit Misuse
................................................................................................ 90
28.
P0715 -03: Clutch Speed Sensor Circuit Signal absent
................................................................................ 95
29.
P0715 -01: Clutch Speed Sensor Circuit Signal Wrong
................................................................................. 98
30.
P0715 -02: Clutch Speed Sensor Circuit Signal Wrong Spikes
.................................................................. 101
31.
P2900 -01: Sport Switch input circuit Switch Stuck
..................................................................................... 104
32.
P0725-02: Engine Speed Input Circuit Signal not valid
............................................................................... 107
33.
P0725-03: Engine Speed Input Circuit Signal Absent
.................................................................................. 110
