15.Install thrust bearing.
NOTE
At the time of assembly the bearing end should
faced towards bottom.
F. COVER ASSEMBLY
1. Position the cover with the open end facing up
on the table.
2. Position the end of needle bearing with the
identification mark up and press drift
(Part
No.287058902605)
into the cover
(If removed)
.
3. Press the ball bearing into cover and install
snap ring.
