HEXA

ELECTRICAL

315

REFITMENT

1.Fit the tweeter on A-pillar by tightening its two

mounting screws. Place the tweeter connector at

its parking position

Tightening torque for Screws -0.5 to 0.6 Kgfm

2.Connect the electrical connection to tweeter.

3.Fit the A-pillar Trim.

REAR DOOR PANEL TWEETERS

1. XT VARIANT

2. Other VARIANTS

LOCATION

It is fitted on Rear door panel.

REMOVAL:

1. Pry out the tweeter from rear door panel.

2. Disconnect the electrical connection of tweeter.

REFITMENT

1. Connect the electrical connection of tweeter.

2. Carefully press the Tweeter into the cutout pro-

vided on rear door panel (Snap fitted).
