890 / 1232
BODY
49
7. Remove 3 screws of the door pull inner.
8. Remove door trim screw, which is located at
the bottom of door.
9. Insert plastic wedge pin & remove the door
trim.
10. Pry out the polyethylene sheet from the door
carefully.
11. Disconnect the electrical connection of the
door latch.
13. Remove the linkages from the door unlock
and lock lever after unscrewing the bell crank
lever bracket.
14.Disconnect the latch linkages (two linkage from
door handle outer and 2 from door lock and
unlock lever inner. In case of auto lock unit
only one linkage from door lock outer to latch.
