9.4.2 REMOVAL OF “A” PILLAR LOWER TRIM:
1. Remove four screws of lower trim by screw
driver.
2.
Remove door beading & Pull lower trim
gently:
3.
Remove A Pillar lower trim
REFITMENT OF “A” PILLAR LOWER TRIM:
1. Match the lower trim holes with holes in body.
2. Refit four lower trim screws by suitable screw
driver.
3. Refit beading.
9.4.3 REMOVAL OF “B” PILLAR TRIMS:
1. Remove Front Seat. “Refer “R+R Front Seat”
2. Remove door Beading: Refer “R+R Bidding”
3. Remove “B” Pillar lower trim two front screw:
4. Unlock “B”
Pillar upper trim from lower and
also unlock 'B' pillar trim lower from front
5. Remove “B”
pillar upper Trim.
