ENGINE 1.3L QUADRAJET (90PS)
14
6.
Place the oil filter housing along with the oil filter
cartridge properly and hand tighten the same and
then tighten it to a torque of 25 N-m using box
spanner.
7. Install the oil filter cover and tighten the two Torx
screws and the hexagonal nut.
C. AIR FILTER INSPECTION AND CLEANING
1. Unscrew the Air filter cover screws.
2. Remove the air filter cover by lifting it on the front
and sliding towards front side of the vehicle.
