Revotron 1.2T
103
NOTE
•
Remove flywheel and camshaft locking pin
11. Remove the Idler & Spacer from the Gear
Train Assembly.
12. Remove Tensioner from the Engine Block.
13. Remove Crankshaft Gear with the Spacer.
14. Remove Woodruff key.
15. Remove the Water Pump assembly along
with the Gasket from the Engine Block.
16. Remove Rear Timing Cover.
