PROPELLER SHAFT
12
4.4.3 OVERHAULING
4.4.3.1 CONSTRUCTIONAL DETAILS
A. PROPELLER SHAFT 4X2 DRIVE
SR.
NO. DESCRIPTION
01 Assembly propeller shaft complete
02 Washer
03 Hexagonal screw M12X35
04 Nyloc nut M12
05 Hexagonal bolt M10X1X40
06 Bright washer
07 Nyloc nut M10X1
08 Torsional vibration damper
09 Full round flange yoke
10 Center bearing assembly
11 UJ kit
(Cold forged)
