FRONT AXLE (4X4)
25
FRONT AXLE
(4X4)
7. Re-position the case in press
(Part No. 2894
5890 35 19)
and remove side bearing cone from
other side in same manner.
NOTE
It is always preferred to replace side bearings once
pulled out. But one can confirm free rolling of bearing
and reuse it, if they are defect free.
8. Loosen and remove the ring gear screws and
remove the ring gear.
9. If required tap ring gear with a mallet to free it
from case.
NOTE
Discard ring gear screws and replace with new one.
10.Install differential case on axle shaft.
11.Use suitable drift to remove the roll pin retaining
cross shaft.
12.Use hammer and punch as shown to remove the
cross pin from case.
