REAR SUSPENSION
41
REAR
SUSPENSION
3. Place the drift
(3)
above and press the same
using press machine to push out the bush from
Pan Hard Rod bush housing.
INSTALLATION
1. Install the Pan Hard Rod bush using special tool
assembly
(Part No.2870 5890 01 09)
as shown in
below arrangement.
2. Place the guide bush
(1)
& mount support
(2)
over the guide bush
(1)
.
3.
Place the Pan Hard Rod bush housing over the
support
(2).
4. Place the bush over the bush housing.
5. Place the drift
(3)
on the bush and press the
same to install the same to install the bush in the
Pan Hard housing.
NOTE
Apply soap and water to the bush, the inner surface
of the tool and the bore of assembly Pan Hard Rod
before installation.
