GEAR BOX
13
14. Loosen and remove the four mounting bolts of
gear box mount.
15. Loosen and remove the mounting nuts (1) from
the rear side of the Gearbox mounting cross
member.
16. Lower the rear end of the gearbox (A) to discon-
nect the cross member from the frame. Slide the
gearbox (B) away from the engine to separate it
from clutch assembly and also clear the suspen-
sion cross member.
17. Carefully lower the gearbox (C) with clutch hous-
ing, gearbox mounting cross member and gear
shifter.
FITMENT
For fitment follow reverse procedure of removal.
