CLUTCH
26
3.1.2.3.3 CLUTCH HYDRAULIC SYSTEM COMPONENTS
ITEM
DESCRIPTION
01
Clamp
02
Assy. High Pressure Line
03
Corrugated Tube Slit 5mm
04
Edge Clamp
05
Peak Torque Limiter
06
Hydraulic Adapter (For CSC)
ITEM
DESCRIPTION
07
Concentric Slave Cylinder
08
Hexagonal Flange Nut
09
Bayonet Adapter with Stud
10
Cap Screw M8 X 50
11
Assy. Clutch Master Cylinder
12
Low Pressure Line
