ENGINE
103
2.1.4.3 EXPLODED VIEW
ITEM
NO.
DESCRIPTION
01
Intake Manifold
02
EGR Cooler
03
Gasket (EGR outlet pipe to EGR Cooler)
04
Assy EGR outlet Pipe
05
Gasket (EGR Intake Pipe to EGR Valve)
06
Assy Adapter - Flange
07
Gasket (Intake Adapter)
08
Intake Adapter
09
Gasket (Intake Manifold to Intake
Adapter)
10
Assy EGR Inlet Pipe
11
Gasket (EGR Intake Pipe to EGR Valve)
12
Gasket (EGR Intake Pipe to EGR Valve)
13
Gasket Intake Manifold
