HVAC
PIN OUT
CONNECTION DETAILS
PIN OUT DESCRIPTION
1
Supply
2
NC
3
To solenoid
4
High
5
Mid
Low
The solenoid valve cab be seen on the underbody
below the second row seat on the RH side.
PIN OUT
CONNECTION DETAILS
PIN OUT DESCRIPTION
1
Ground
2
Supply
