SAFARI

486 PL ENGINE

CONSTRUCTION :

Functions of keys of KTS 300 system tester are given below :

Note

For details of using KTS 300 and to prevent damage to the equipment, please read carefully the operating

instruction manual supplied along with the Diagnostic kit.

6 pin port for printer

Selection keys

Return to next

highest pgm. level

LCD screen

Previous Page

Storing Indication

Rubber Protector

8 Pin port for diagnostics / charging.

Next Page

Play back stored data

Help Menu

Fig. 190
