1.2L REVOTRON ENGINE

28

Oil Sump

No.

DESCRIPTION

NO REUSE

SEALANT

LUBRICATION

TORQUE

(Kgf.m)

1 Oil Sump

2 Sealing Washer

3 Drain Plug

3.5

4

H/FL Screw M6X14 for Oil Sump (18

Qty)

1.0

5 H/FL Bolt M8X45 for stiffener (2 Qty)

2.5

6 Stiffener

7 H/FL Screw M6X14

1.0

8 Water Bypass Bracket

9 Water Bypass Assembly

10 Pipe seal
