TIAGO

40 / 1002

1.2L REVOTRON ENGINE
3
C. TECHNICAL SPECIFICATION :
Model :- 1.2L REVOTRON
Description 1.2L NA NG REVOTRON 110 377 DOHC VCT BS-IV
Type :- Gasoline 4-stroke MPFI, inline 3 cylinder with 4 valves per
cylinder.
Engine Configuration :- Transverse mounted inline 3-cylinder engine
Engine Management
System :- BOSCH Engine Management System / Cube Lite
Bore/Stroke :- 77 mm X 85.8 mm
Engine Capacity :- 1199 cc
Radiator Coolant :- Class II/JIS K2234 TATA SS7700, Coolant ratio 60:40
Compression Ratio :- 10.7
Maximum Engine Power
Output
:- 85 PS @ 6000rpm
Maximum Engine Torque
Output :- 114.4Nm @ 3500 +/- 70 rpm
Engine Firing Order :- 1-2-3
Oil Capacity :- 3.5 L
Cooling System Capacity :- 4 lit. (water + coolant)
Spark Plug Type :-
BOSCH : YR7SES (0.7 to 0.8 mm gap)
FM : RER8MC (0.8 to 0.9 mm gap)
Air Filter :- Engine Mounted, Dry Paper Cartridge type.
Oil Filter :- Spin on Full flow Paper type
Fuel Filter Composite Filter Element (Max Working Pressure 500Kpa
Timing :- Chain Drive
VCT DENSO Controller Assy
Emission Norms :- Bharat Stage lV Compliance
Ignition Coil Details :- Epoxy Molded Coil Type Ignition Coil (Supply Voltage 5-16V)
