3 CYL PETROL ENGINE

111

4. Remove the CCC left side support bracket

near Compressor.

5. Remove Closed Coupled Catalytic Convertor

and Gasket.

6. Remove Thermostat Cover by 3 bolts.

7. Remove Thermostat

8. Remove the Oil Filter assembly by using

Special Tool.

SPECIAL TOOL



Oil Filter Spanner -

5424 5890 18 02

NOTE



Ensure Oil Spillage to be gathered in

oiltub.

9. Remove front and rear Lifting Hook from

Cylinder Head.
