3 CYL PETROL ENGINE
94
17. Connect the vacuum hose connected between
brake booster to vacuum pump.
18. Connect all the hoses connected between
radiator and engine.
19. Connect the fuel lines to the engine.
20. Install the Battery Plate, Battery and ECU.
21. Connect the engine wiring harness connection
with ECU.
22. Add the appropriate quantity of Engine oil,
Transaxle oil and coolant with respective
systems.
23. Connect the battery positive cable and then
the battery negative cable.
24. Crank the engine several times without
allowing the vehicle to start. This allows the oil
and coolant to flow through engine.
25. Start the engine and verify the oil pressure
light on the instrument cluster goes out. Stop
the engine immediately if the light fails to
extinguish.
26. Allow the engine to run for several minutes,
checking for fluid levels and leakage.
B. AIR FILTER ASSEMBLY REMOVAL
1. Remove the snorkel from snorkel mounting
bracket.
2. Disconnect the all hose clips.
3. Remove the Air filter mounting bolts (2 nos.).
4. Remove the air filter from grommet in upward
direction
and remove out from vehicle.
FITMENT
For fitment follow the reverse order of removal.
